Efficient tools and jigs that are easy to work

Our tooling and jigs help improve quality, increase production volumes, and diminish human error. Integrating parts created via 3D printing offers production operators, specialists and technicians an advantageous alternative to traditional tooling.

We can manufacture a variety of products:

  • Inspection jigs
  • Production jigs
  • Finishing and masking tools
  • Ergonomic tools for operators
  • Forming tools (composites, thermoforming, single die sheet hydroforming, etc.)
Efficient tools and jigs that are easy to work

Improve your production quality and efficiency

Make sure your equipment is ergonomic

Our specialized tooling and jigs are designed to take advantage of 3D printing and boost work method efficiency, thanks to:

  • Greater comfort for the operator;
  • Lighter weight and easier handling;
  • Decreases in occupational illness and work accidents;
  • Lower cycle durations.

Enjoy the advantages of 3D printing:

  • The technology allows greater design freedom;
  • Our production processes significantly cut down on the need for tooling, thanks to the use of effective thermoplastics;
    For example, we have produced 30 lb (plastic) versus 150 lb (traditional metal) tooling;
  • The design is optimized based on the operator’s needs rather than the manufacturing process.
Make sure your equipment is ergonomic

Save time and money

Integrating our specialized tooling into your production processes can significantly shorten your timeframes.

  • Hybrid tooling* speeds up the design process;
  • Standard industry deadlines for delivery can be cut in half;
  • Production workflows can be maintained thanks to high production speed;
  • Our specialized tooling design techniques facilitate maintenance and repairs.

*Combination of 3D printing and traditional building.

Lower your cost by integrating 3D-printed parts:

  • Avoid the programming fees required for complex shapes;
  • Take advantage of higher production speeds: 2 to 8 weeks (hybrid tooling) versus 12 to 20 weeks (100% traditional tooling);
  • Add protection to avoid breakdowns and failures in hybrid tooling.
Save time and money

Guarantee your project’s success

Hybrid tooling and jigs generate immediate advantages that are reflected by improved productivity, efficiency and quality.

Count on Solaxis and its expertise :

  • We use an anti-error (poka-yoke) system to achieve “zero defect.” This means quality controls required to detect production defects can ultimately be eliminated;
  • Enjoy a final turnkey product thanks to:
    • In-depth needs analysis
    • GD&T expertise
    • Project management to guarantee that all goes according to plan
    • On-site finishing and assembly
    • A certificate of dimensional compliance
  • Iterations can be performed swiftly and without constraints, given that a single section of the tooling or jig can be printed again.
Guarantee your project’s success

Example of achievement

3D Industrial Tooling | Go/ NoGo

3D Industrial Tooling | Go/ NoGo

Customer

Ground transportation

Mandate

Produce a Go/NoGo to regularly check part compliance.

Goals

  • The tool had to be moved several times a day for validation purposes. As a result, the customer asked us to produce lightweight tooling that would facilitate safe movements for the operator.
  • The project had to be completed within short timeframes.

Case study



RAPID-RESPONSE TOOLING

RAPID-RESPONSE TOOLING

Customer

Aerospace

Mandate

To cut lead time for customized composite tooling by embracing 3D printing

Goals

The latest technique that SSL has implemented is additive manufacturing for rapid-response, customized, high-temperature lay-up tooling. Although often overlooked, tooling applications are proving to be among the most effective use cases for realizing significant and immediate value with additive manufacturing.
